Easy Gripper 3400-5T

Professional tools for handling of OTR/EM tyres up to 36.00R51

Unique and safe 3-point grip
Precise rotation +/-25°
35° or 90° tilt horizontal to vertical
Integrated camera system for optimal view
Tools for safe handling of tyre rings and rim
Prevent damage to tyres, rims & equipment
Easy hook on/off attachment
Customization on request

Capability

The Easy Gripper 3400-5T has a gripping range of Ø1.380 – 3.400 mm (55 – 133”) and a lifting capacity of 5.000 kg (11.000 lbs) at a CoG of 650 mm (26”).

For almost any type of carrier

Depending on the tilt capability of the carrier vehicle, the Easy Gripper 3400-5T is available with either a 90° tilt module for forklifts, a 35° tilt module, or in a compact version without tilt for use on telehandlers, and wheel loaders.

Standard features

Unique and safe 3-point grip
Prevents accidents.
Prevents deformation of tyres.
Prevents damages to tyres, rims and equipment.
Integrated camera system with 2 cameras
For optimal view and for precise hub and bolt alignment.
With automatic IR function in insufficient lighting conditions.
Control system with pressure indicator
Precise rotation +/-25°
35° or 90° tilt module, horizontal to vertical
LED working light
Customized attachment system

Optional accessories

Quick Shift Solution
A quick-shift solution can be included. This allows for versatile use of the carrier.
Easy shift of gripping pipes for various purposes
Telescopic pipes for long reach, to provide room for the tyre fitter and for dual tyre handling.
Flat top pipe for limited clearance between tyre and mudguard
Ring Handling Tools Tools for safe handling of multi-piece rim wheels
Enables the tyre fitter to handle Locking Rings, O-Rings, Side Rings and Bead Seat Bands in a safe and secure manner.
RIM Handling Tools
The RIM Handling tools are yet a safety and efficiency add-on to the Easy Gripper program and improve the handling of OTR rims.
Customization on request

What our customers say

“The Easy Gripper gives our workers excellent ergonomic working conditions, and during the use of it we have realized, that the safety the Easy Gripper delivers has no comparison.”

Fernando Balart Austral Mining Services

Read Case Story

Interested in this product?

Brochure

PDF

Technical Data

Weight: Compact = 3.050 kg / 35° = 3.200 kg / 90°= 3.300 kg
Lifting capacity:
– 5.000 kg (11.000 lbs) at (C) from (B) 650 mm (25.6”)
– 4.000 kg (8.800 lbs) at (D) from (B) 1.300 mm (51.2”)
Tyre diameter: 1.380 – 3.400 mm (54.3 – 133.9”)
Standard pipes: Ø216 x 1.115 mm (8.5” x 43.9”)
Telescopic pipes: Ø236 x 1.115 -> 1.890 mm (9.3” x 43.9” -> 74.4”)

Technical Requirements

Lifting capacity: Minimum 14 – 18 ton depending on carrier
Attachment: Terminal West / Loader specific
Electrical supply: 24V / min 10A
Hydraulic supply: 1 double acting circuit (A+B port)
Pressure min-max: 150 – 250 bar (2.175 – 3.626 psi)
Return pressure: max. 10 bar (145 psi)
Flow: max. 75 l/min. (19,8 gal/min.)

Easy Gripper 3400-5T Compact - spec drawing

Compact
(A) CoG Gripper = 835 mm (33”)
(B) Face of Gripper = 1.030 mm (41”)
(C) CoG Load1 = 1.680 mm (66”)
(D) CoG Load2 = 2.330 mm (91.7”)

Easy Gripper 3400-5T - 35 degree tilt module - spec drawing

35° tilt module
(A) CoG Gripper = 980 mm (38.6”)
(B) Face of Gripper = 1.320 mm (52”)
(C) CoG Load1 = 1.970 mm (77.6”)
(D) CoG Load2 = 2.620 mm (103”)

Easy Gripper 3400-5T - 90 degree tilt module - spec drawing

90° tilt module
(A) CoG Gripper = 1.410 mm (55.5”)
(B) Face of Gripper = 1.760 mm (69.3”)
(C) CoG Load1 = 2.410 mm (94.9”)
(D) CoG Load2 = 3.060 mm (120”)

Improve safety and efficiency

The unique 3-point grip, precise tilt and rotation, integrated camera system and special designed Ring Handling Tools all improves the safety as well as the efficiency while handling tyres and wheels.

Optimized tyre logistics

Stacks tyres both horizontal and vertically at workshops and warehouse areas. Fast and safe loading and unloading of trailers.

Mobile and on-site tyre service

Mounted on forklifts, front loaders or telehandlers all tyre service situations in all environments can be handled in the mining industry and civil construction.

OEM assembly lines

The Easy Gripper has full control of the tyres and wheels during the whole process, until it is firmly mounted on a vehicle. Proven record of reducing internal damages with up to 90%.
